Local air conditioner PAC 3900 X + Airlock 1000
Availability: Immediately available
Local air conditioner PAC 3900 X
Triple power for more freshness: cooling, ventilation, dehumidification
A comfortable range of functions and cooling technology of the latest generation make the multi-functional air conditioner PAC 3900 X a true all-rounder. Whether cool, ventilate or dehumidify: the ultra-compact air conditioner masters all the requirements of an optimal indoor climate with flying colors. With a cooling capacity of 3.9 kW, the air conditioning unit of the PAC series is recommended as a cooling solution for large rooms up to 130 m³. In addition to reliable cooling on hot days, the PAC 3900 X also filters and dehumidifies the air in the room, providing a breath of fresh air. On request in three ventilation levels and with swing function, for optimum air distribution in the room.
Functions of PAC 3900 X
Refreshingly more comfort. As flexible as possible.
The PAC 3900 X features state-of-the-art microprocessor control with a variety of custom programmable functions. Optionally, the device also takes over the regulation of the room climate on its own. Even the energy costs are automatically reduced by the intelligent air conditioning unit by automatically switching off the air conditioning compressor and fan when the preset target temperature is reached.
Savings tip! The operating modes ventilation and dehumidification can also be selected with the cooling function deactivated. Thus, the 3-in-1 air conditioner PAC 3900 X can be used all year round to create a pleasant and healthy living environment - at the same time lower power consumption. This reduces the energy consumption of the already economical device noticeably and makes the purchase of a separate dehumidifier or fan superfluous.
An hourly operation, as well as the automatic switching on and off of the device, allows the integrated timer function. For a restful sleep and the necessary regeneration of the body provides the pleasantly quiet night function with an adapted temperature control.
More time for the essentials! The set operating parameters such as device mode, target temperature and ventilation intensity remain stored after the device has been switched off and are automatically taken over the next time the device is switched on. Combined with a timer, the PAC 3900 X is ideal for creating an optimal indoor climate in offices or private rooms, unattended and at fixed times.
The PAC 3900 X monoblock air conditioner can be controlled either via the supplied IR remote control or via the clearly arranged membrane keypad control panel on the device.
Installation and Maintenance of the PAC 3900 X
Ready to use in a jiffy.
The pre-assembled air filter can be easily removed and cleaned if necessary. The moisture is collected as condensate in a collection container. A permanent condensate drain can be connected on the back if required.
Tip: Use the convenient AirLock window or door seal to attach the supplied exhaust hose. This ensures a cold-loss-free window or door leadthrough and allows the hose to be attached to any type of window (sash, tilt, roof pitched window) or door (sash or tilt door). The AirLock increases the cooling efficiency of your air conditioner and reduces the consumption costs.
Mobile, space saving, low maintenance
Small in size, flexible in use, smart design.
Today in the bedroom, tomorrow in the living room? No problem, the relocation is done easily and quickly thanks to the smooth running wheels and the ergonomically shaped recessed grip. The practical cable rewind simplifies the trouble-free storage of the device after the cooling season.
An air conditioner, many uses
With its three operating modes, cooling, ventilation and dehumidification, the high-performance PAC 3900 X is recommended as a flexible all-rounder in the office or at home.
Benefits for the practice:
- Energy efficiency class A
- 3.9 kW cooling capacity
- Three operating modes: cooling, ventilation, dehumidification
- Three ventilation levels
- Timer function
- Auto-restart function for use with an external timer
- Practical LED display
- Easy to clean membrane keypad
- Display of room temperature
- Swing function for optimal air distribution
- IR remote control
- Removable air filter
- Quiet operation <53 dB (A)
AirLock from Trotec is Europe's best-selling window seal for combined use with one- or two-hose air conditioning units. The AirLock 1000 window seal extends the application possibilities of this practical accessory-set as it can also be used on terrace and balcony doors, as well as windows at ground level.
With the AirLock 1000, you can finally profit from the advantages of an energy-saving window sealing even with doors or very large windows!
The AirLock 1000 is the only window seal on the market to measure 560 cm. This makes the AirLock 1000 the first choice for the sealing of balcony and terrace doors or windows at ground level with rotary locks/tilt locks.
The exhaust air window seal AirLock 1000 can be installed between door or window and frame with just a few steps and has two variably adjustable zipper openings into which an exhaust hose end piece can be clamped seamlessly and precisely. This prevents the backflow of warm outside air into the room, which not only reduces the power consumption of your air-conditioning unit, but also prevents insects from entering the room.
If only one opening is required, the second zip opening remains simply invisible and air-tight. When leaving the house, the doors or windows can be closed without having to dismount the AirLock beforehand.
Benefits in practice:
Energy-saving door and window sealing
Increases cooling performance, reduces energy consumption
Ideal for terraces and balconies or windows at ground level
Thanks to two zipper openings, it is suitable for air-conditioning units with single-hose and two-hose technology
Variable to fit all hose diameters
Water resistant and washable
Prevents the penetration of warm air and insects
The window can be closed despite window sealing
Pays for itself in the shortest possible time
Easy self-assembly
Residue-free disassembly
| Technical data | ||
|---|---|---|
| General information | ||
| Article number | 1.210.002.130 | |
| Type | ||
| Monobloc | ||
| Split | ||
| Cooling capacity | ||
| Max. cooling capacity [kW] | 3.9 | |
| Max. cooling capacity [Btu/h] | 13,300 | |
| Recommended room size | ||
| m³ | 130 | |
| m² | 52 | |
| Air flow rate | ||
| Level Max. [m³/h] | 420 | |
| Fan | ||
| stages | 3 | |
| Radial | ||
| axial | ||
| Dehumidification performance | ||
| Max. dehumidification performance [l/h] | 3.7 | |
| Attainable room temperature | ||
| (min.) depending on operating conditions [°C] | 17 | |
| (max.) depending on operating conditions [°C] | 30 | |
| Cooling medium | ||
| Cooling medium | Air | |
| Ambient conditions | ||
| Min. temperature range [°C] | 17 | |
| Max. temperature range [°C] | 35 | |
| Electrical values | ||
| Mains connection | 220 - 240 V, 50 Hz | |
| Power input [kW] | 1.9 | |
| Nominal current consumption [A] | 8.6 | |
| Recommended fusing [A] | 10 | |
| Electric connection | ||
| Connection plug | CEE 7/7 | |
| Cable length [m] | 1.4 | |
| Compressor | ||
| Minimum room size [m²] | 13 | |
| refrigerant | R290 | |
| Amount of refrigerant [g] | 280 | |
| GWP factor | 3 | |
| CO2 equivalent | 0.00084 | |
| Pressure suction side [MPa] | 1 | |
| Pressure outlet side [MPa] | 2.6 | |
| Sound values | ||
| Noise emission [dB(A)] according to EN ISO 3745:2012 | 65 dB(A) | |
| Level 1 - Distance 1 m [dB(A)] | 52.5 | |
| Exhaust air | ||
| Total length [m] | 1.5 | |
| Diameter [mm] | 148 | |
| Dimensions | ||
| Length (packaging excluded) [mm] | 400 | |
| Width (packaging excluded) [mm] | 470 | |
| Height (packaging excluded) [mm] | 760 | |
| Weight | ||
| (packaging excluded) [kg] | 35 | |
| Equipment, features and functions | ||
|---|---|---|
| Condensate draining | ||
| With condensate drain | ||
| With condensation tray | ||
| Timer function | ||
| Switch-on time preselectable | ||
| Switch-off time can be preselected | ||
| Room thermostat | ||
| Available | ||
| Room air filter | ||
| Cleanable | ||
| Readily accessible | ||
| Additional functions | ||
| Dehumidification function | ||
| Ventilation function | ||
| Automatic function | ||
| Automatic fault diagnosis | ||
| Swing function | ||
| Sleep mode | ||
| Energy saving mode | ||
| Fan rundown function | ||
| Auto restart function | ||
| Control panel | ||
| Mikroprozessorgesteuerter Betrieb | ||
| Infrarot-Fernbedienung | ||
| Membrantasten | ||
| LED display | ||
| Mobility | ||
| Plastic wheels | ||
| Carry/transport handle(s) | ||
| Housing design | ||
| Plastics | ||
standard equipment
optionally available
not available
| Technical data | ||
|---|---|---|
| General information | ||
| Article number | 6.100.002.004 | |
standard equipment
optionally available
not available
